Now compatible with Active Imaging™

Download now

Active Imaging™

Perfect for pinpointing fish-holding areas like rockpiles, wrecks, bridge pilings, ditches and drop-offs, highresolution Active Imaging™* allows anglers to see structure and cover in extreme high-resolution detailat a greater distance from the boat than any other structure imaging technology. The NOS 18.3 software
update enables support for both Active Imaging™ 3-in-1 (CHIRP | SideScan | DownScan Imaging™) and 2-in-1 (SideScan | DownScan Imaging™) transducers.
*NSS evo3 and GO series only

StructureScan® 3D Active Imaging Enhancements

Anglers will have an easier time pinpointing prime fishing areas with higher-resolution, three-dimensional views of structure and cover included with the Active Imaging™ enhancements for StructureScan® 3D. Enhancements include a cleaner water column with less noise, refreshed color palettes and improved sonar processing to deliver the maximum amount of detail – plus a new
depth-highlighting feature that colors the userselected upper- and lower- depth limit area to help anglers better isolate specific structure and bottom depth.

*NSO evo3 and NSS evo3 only

Quick and Easy Access to Sonar

Anglers will get quicker, one-touch access to all of their sonar via a simplified NSO, NSS and GO series interface, featuring dedicated sonar pages for Echo, SideScan, DownScan Imaging™ and StructureScan® 3D. New custom split-screen panel configurations are also available that allow anglers greater control over the display of splitscreen panels – the perfect way to showcase the new Simrad® capability to display SideScan, DownScan Imaging™ and StructureScan® 3D on the same screen, at the same time.

Enhanced Amplitude Scope

Amplitude Scope enhancements for NSO evo3/evo2 and NSS evo3/evo2 displays integrate advanced sonar data into the scope, including new onscreen indicators for the location of the bottom and gain level, plus the option to display the scope horizontally across the screen.

Dual Mode Wifi

With Dual Mode WiFi, you can maintain a WiFi connection to NSO and NSS evo3 and still use them as an access point for screen mirroring/remote control from a smartphone or tablet via the
Link app. Prior to the NOS 18.3 software upgrade, NSO and NSS evo3 displays could only perform one of the tasks at a time – connecting to the
internet or serving as an access point for screen
mirroring/remote control.
